Module III: Introduction to working with Point Clouds

Introduction

Module III teaches how to import and process ASCII point cloud data in Virtual CRASH to build a 3D terrain mesh.

Reading Assignment

If you have not done so already, please read the following:

  • Using Point Clouds in Virtual CRASH (VC6 | VC5 | VC4)

  • The Easy Surface Builder in Virtual CRASH (VC6 | VC5 | VC4)

Video Lecture

  • Before starting video, please download files: Environments_Module3 (VC4 | VC5 | VC6), Neighborhood_Scan_xyzargb_meters.pts

  • VC4 and VC5 users, please download Jeep Wagoneer (VC4 | VC5) and use Project > Import (or drag and drop) to place the vehicle into your scene.

  • Complete the project shown in the Module III video below. Keep the project open and use it to answer the quiz questions.

  • IMPORTANT: Watch each video through to the end to reach the final quiz. Quizzes are embedded throughout and must be completed as you go in order to continue. In most cases, questions are multiple choice with one correct and three incorrect answers, and you'll need 3 of 4 correct to pass. If you fail, you can review the prior section or retake the quiz. You can't skip ahead, and quizzes must be answered in order. Plan to watch each video in one sitting, since restarting one means retaking its quizzes. Once you complete the final quiz, a "Module Complete" pop-up will appear. Left-click the "copy code" button, enter your email address, and press SUBMIT below.

Once you pass all quizzes for this video, paste the validation code below (Ctrl+V), enter your email, and press the SUBMIT button.
